Guide Handheld Thermal Cameras

PS800 specifications

<strong>Imaging and optics</strong> Detector type;VOx Infrared resolution;1024 ×768@12 μm Super resolution technology;Yes, Upgrade to 2048 ×1536 Wavelength range;7.5 to 14 μm Focal length;28 mm Field of view;25°×19° Minimum object distance;0.3 m D:S;2325:1 NETD;≤30 mK Infrared frame rate;25 Hz / 9 Hz Focusing mode;Electric / Manual Digital zoom;1.1x to 35x Shot recognition;Auto / Manual <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 100°C to 800°C, Optional 700°C to 2000°C (High temperature lens is required) Measurement accuracy;±1°C or ±1%, whichever is greater Analyzed target;Spot ×30, Line ×30, Area ×30 Tracking / Alarm;Full screen maximum, minimum and average temperature tracking<br/>The maximum, minimum and average temperature tracking of analyzed target<br/>Full screen temperature threshold alarm (image and voice) Isothermals;Available Temperature measuring parameters;Emissivity, reflected temperature, target distance, humidity, atmospheric transmittance, optical transmittance <strong>Image display</strong> Display screen;5’’ LCD Eyepiece;1, 280 ×960 LCOS screen Digital camera;13 MP Image mode IR, VIS, MIF and PIP Image adjustment;Automatic, semi-automatic, manual Color palettes;White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Customized <strong>Storage and transmission</strong> Storage media;Local storage (64 GB) and SD card (64 GB and up to 128 GB) Image storage format;JPG with temp info Video storage without temperature information;MP4 format can be used to record audio synchronously Video storage with temperature information;Irgd for temperature analysis External interface;Type-C, DC (12V) , SD card slot, Network port, Micro HDMI, UNC ¼"-20 (Tripod mounting) Laser;630~670nm, Class 2 laser, ＜1mW, indicating the measured target and laser ranging Audio;Recording and playback through microphones and speakers respectively WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission GPS;Available Bluetooth;Available 4G / 5G;4G module (optional) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Battery working time;≥3 hours Power management;Timed shutdown and sleep mode Charging mode;The device can be charged through desktop charger after shutdown. Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C Storage temperature;-40°C to 70°C IP rating;IP54 Certification;CE, FCC, ROHS, KCC, Anatel, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Weight;≤1.5 Kg (with battery) Size (L ×W ×H);206 ×169 ×135 mm Software kit;ThermoTools Standard;A device, Lens cover, Lithium-ion battery, Power adapter, Adapter plug (5) , TYPE-C USB cable, Micro HDMI cable, Network cable, Quick Start Guide, Instructions, Data download card, SD card (64 GB) , Shoulder strap, Carrying case, Factory certificate, Desktop charger Options;Lithium-ion battery, Carrying bag, Bluetooth headset, Expanded lens, 4G module, Tripod <strong>Standard Lens</strong> Focal length;28 mm FOV;25°×19° IFOV;0.43 mrad Min focus distance;0.3 m <strong>Standard Lens+Wide Angle (48°×35°)</strong> Focal length;15 mm FOV;45°×34° IFOV;0.8 mrad Min focus distance;0.1 m <strong>Standard Lens+Medium Telephoto (11°×8°)</strong> Focal length;45 mm FOV;15°×11° IFOV;0.27 mrad Min focus distance;3 m <strong>Standard Lens+Telephoto (7°×5°)</strong> Focal length;75 mm FOV;9°×7° IFOV;0.16 mrad Min focus distance;5 m <strong>Standard Lens+Macro Lens</strong> Working distance;67 mm Object/target Size;23.3 mm×17.5 mm Spatial Resolution (IFOV);60.7 μm <strong>Standard Lens+High Temp</strong> FOV;25°×19° Temp Measurement Range;-40°C to 2000°C

PS610 specifications

<strong>Imaging and optics</strong> Detector type;VOx, Focal Plane Array (FPA), uncooled microbolometer Infrared resolution;640x480@17 μm, non-interpolate Super resolution technology;Yes, Upgrade to 1280x960 Wavelength range;7.5 to 14 μm Focal length;25 mm Field of view;25° x 19° Minimum object distance;0.3 m D:S (IFOV);1470:1 (0.68 mrad) NETD at 30°C (at 30 Hz image frame rate);≤ 30mK Infrared frame rate (on display);30 Hz, non-interlaced Focusing mode;Automatic and Electric (Manual) Digital zoom;1.1x to 35x Shot recognition;Auto / Manual <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 100°C to 800°C, Optional 700°C to 2000°C (High temperature lens is required) Measurement accuracy;±1°C or ±1%, whichever is greater Analyzed target;20 in total (Spot/Line/Area), Auto maximum and minimum temperature Tracking / Alarm;Full screen maximum, minimum and average temperature tracking/The maximum, minimum and average temperature tracking of analyzed target/full screen temperature threshold alarm (image and voice) Isothermals;Available Temperature measuring parameters;Emissivity, reflected temperature, target distance, humidity, atmospheric transmittance, optical transmittance Emissivity Correction;Variable from 0.01 to 1.0 or select from listings in pre–defined materials list (at 0.01 step) Reflected ambient temperature;Automatic, base on input of reflected temperature <strong>Image display</strong> Display screen;5’’ LCD Eyepiece (Viewfinder for outdoor inspection);Color built-in Viewfinder : 1, 280 × 960 LCOS screen Digital camera;13 MP, full color Image mode;IR, VIS, MIF and PIP Image adjustment;Automatic, semi-automatic, manual Color palettes;White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Customized <strong>Storage and transmission</strong> Storage media;Local storage (64 GB) and SD card (64 GB and up to 128 GB) Image storage format;24 bit radiometric IR digital image Visual image;Visual image shall be linked with the corresponding thermal image Video storage with temperature information;Irgd for temperature analysis External interface;USB Type-C, DC (12V) , SD card slot, Network port, Micro HDMI, UNC ¼ "-20 (Tripod mounting) Audio;Recording and playback through microphones and speakers respectively WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission GPS;Available Bluetooth;Available 4G / 5G;4G module (Optional) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Battery working time;≥3 hours Power management;Timed shutdown and sleep mode Charging mode;The device can be charged through desktop charger after shutdown <strong>Environmental parameters</strong> Weight;≤1.35 Kg (with battery) Working temperature;-20°C to 50°C Storage temperature;-40°C to 70°C IP rating;IP54 Certification;CE, FCC, ROHS, KCC, Anatel, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Complete With</strong> Accessories;Sixty (60) seconds voice annotation with each image file, Video output port, Communication Cable, Standard Lens and Telephoto (IFOV for Telephoto lens not more than 0.4 mrad) One (1) set battery charger and two (2) sets battery, Optional extra batteries, AC Power Adaptor, single phase, 230 V AC, 50 Hz, Transport Case, Instruction Manual in English and Thai Other accessories according to manufacturer's design and auxiliary equipment necessary to complete. <strong>Data Analysis and Reporting Software</strong> Software;Comprising useful function for Windows operating system, with Thumbnail image viewer, support drag and drop transfer of selected images from PC card to computer independent emissivities correction variable from 0.1 to 1.0 or select from listings in predefined materials list (at 0.01 step), spot tools, area tools and line tools with maximum, minimum and average temperature, and Delta T calculation function, voice note replay, wizard driven report generation, the report can be modified by user

PS600 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;640×480@17μm Super resolution;Yes, upgrade to 1280×960 NETD;40 mK Frame rate;30Hz/9Hz Focal length;25 mm Field of view;25°×19° IFOV;0.68 mrad Min. object distance;0.3m D:S;1470:1 Focusing mode;Automatic/Electric Digital zoom;1.1x to 35x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 100°C to 800°C, Optional 700°C to 2000°C (High temperature lens is required) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;16 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image and voice) Parameter settings;Emissivity, reflected temperature, target distance, humidity, atmospheric temperature, optical transmittance Others;Customized physical button <strong>Image display</strong> Display screen;5” LCD, touch screen, 1280×720 Eyepiece;LCOS screen, 1280×960 Image mode;IR, VIS, MIF and PIP Color palettes;10: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;13MP <strong>Functions</strong> Laser;Laser (Indication, Ranging) Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and SD card (64 GB and up to 128 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) for temperature analysis External interface;USB-C, DC (12V) , SD card slot, Network port, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;4G module (optional) Bluetooth;Available <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours Charging mode;The device can be charged through desktop charger after shutdown. Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Certification;CE, FCC, RoHS, KCC, Anatel, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator, Microphone, Speaker, Electronic Compass, GPS Weight;1.35 kg (with battery) Size;206×145×135 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device, Lens cover, Lithium-ion battery, Power adapter, Adapter plug, USB-A to USB-C Cable, Micro HDMI to HDMI Cable, RJ45 Ethernet Patch Cable, Quick Start Guide, Instructions, Data download card, SD card (64 GB) , Shoulder strap, Carrying case, Factory certificate Options;Lithium-ion battery, Carrying bag, Desktop charger, Bluetooth headset, Expanded lens, 4G module, Tripod

PS400 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;384×288@17 μm Super resolution;Yes, Upgrade to 768×576 NETD;45 mK Frame rate;30Hz/9Hz Focal length;15 mm Field of view;25°×19° IFOV;1.13 mrad Min. object distance;0.15 m D:S;885:1 Focusing mode;Automatic/Electric Digital zoom;1.1x to 10x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 100°C to 800°C, Optional 700°C to 2000°C (High temperature lens is required) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;12 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image and voice) Parameter settings;Emissivity, reflected temperature, target distance, humidity, atmospheric temperature, optical transmittance Others;Customized physical button <strong>Image display</strong> Display screen;5” LCD, touch screen, 1280×720 Eyepiece;LCOS screen, 1280×960 Image mode;IR, VIS, MIF and PIP Color palettes;8: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;8 MP <strong>Functions</strong> Laser;Laser (Indication, Ranging) Recording function;Photo and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and SD card (64 GB and up to 128 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) for temperature analysis External interface;USB-C, DC (12V) , SD card slot, Network port, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;4G module (optional) Bluetooth;Available <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours Charging mode;The device can be charged through desktop charger after shutdown. Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Certification;CE, FCC, RoHS, KCC, Anatel, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator, Microphone, Speaker, Electronic Compass, GPS Weight;1.35 kg (with battery) Size;206×145×135 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device, Lens cover, Lithium-ion battery, Power adapter, Adapter plug, USB-A to USB-C Cable, Micro HDMI to HDMI Cable, RJ45 Ethernet Patch Cable, Quick Start Guide, Instructions, Data download card, SD card (64 GB) , Shoulder strap, Carrying case, Factory certificate Options;Lithium-ion battery, Carrying bag, Desktop charger, Bluetooth headset, Expanded lens, 4G module, Tripod

PF210 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;256×192@12 μm NETD;45 mK Frame rate;25Hz/9Hz Focal length;3.2 mm Field of view;56°×48° IFOV;3.75 mrad Min. object distance;0.3 m D:S;266:1 Focusing mode;Focus-free Digital zoom;1.1x to 8x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 100°C to 550°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Spot×2 (Include Center spot), Area×3 Alarm;Full screen temperature threshold alarm (image and flash) Parameter settings;Emissivity, reflected temperature, target distance Others;Customized physical button×2 <strong>Image display</strong> Display screen;3.5" LCD Image mode;IR, VIS, MIF and PIP Color palettes;6: White Hot, Black Hot, Iron Red, Hot Iron, Rainbow, Arctic Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;5 MP <strong>Functions</strong> Laser;Laser (Indication, Ranging) Recording function;Photo Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (16 GB) Image storage;JPG with temp info External interface;USB-C, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image transmission <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;4 hours Charging mode;USB-C charging, PC/portable charger, Capable of charging while using Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-10°C to 50°C IP rating;IP54 Drop;1 m drop test Certification;CE, FCC, RoHS, KC, Anatel, IP54, 1 m drop test, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator Weight;296g Size;138×89×34 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device, Wrist strap, Carrying bag, Quick Start Guide, Power adapter, Adapter plug, USB-A to USB-C Cable, Data download card, Certificate of approval Options;Tripod

PV400 specifications

<strong>Imaging and optics</strong> Detector type;Cooled, HgCdTe/MCT, 3.2 μm ~ 3.5 μm Infrared resolution;320×256@30 μm Super resolution;Yes, Upgrade to 640×512 NETD;Detector NETD ≤10 mK Frame rate;50 Hz Focal length;23 mm Field of view;24°×18° IFOV;1.3 mrad Min. object distance;1 m D:S;769:1 Focusing mode;Manual/Automatic Digital zoom;1x to 10x <strong>Measurement and analysis</strong> Measurement range;IR mode: -40 ~ 350 °C, Gas mode: -40 °C ~ 60 °C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Supports adding up to 15 analyzed targets (including a maximum of 15 spots, 2 lines, 4 circles, and 4 rectangles) Alarm;Full screen temperature threshold alarm (image, voice and flash) Parameter settings;Emissivity, reflection temperature, target distance, humidity, atmospheric temperature, optical transmittance Others;Customized physical button, OTA update <strong>Image display</strong> Display screen;4.3’’ LCD, touch screen, 800×480 Eyepiece;OLED screen, 1024×768 Image mode;IR, VIS, MIF, PIP, Gas mode (support GDEMode) Color palettes;12: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;8 MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 40m) Recording function;Photo and Video (infrared & visible light) Cloud Services;Available Gas detection;Gas detection sensitivity: ≤ 0.4g/hr (CH4). Gas types: methane, ethane, propane, butane, pentane, hexane, heptane, octane, ethylene, propylene, isoprene, methanol, ethanol, butanone, benzene, toluene, xylene, ethylbenzene, etc <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (128 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) External interface;USB-C, DC (12V) , SD card slot, Micro HDMI, RJ45, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;5G module (optional) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours Charging mode;The device can be charged through desktop charger after shutdown. Charging time;90% of full charge in 2.5 hours, revealed by the status screen <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Certification;CE, FCC, RoHS, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator×2, Microphone, Speaker, Electronic Compass, GPS Weight;3.36 kg (with battery) Size;297×167×204 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-A to USB-C Cable, Micro HDMI to HDMI Cable, RJ45 Ethernet Patch Cable, SD card (128 GB), Wrist strap, Safety box, Quick Start Guide, Data download card, Certificate of approval, Factory certificate Options;Lithium battery, Tripod, Carrying bag, 5G module

PT870S specifications

<strong>Imaging and optics</strong> Core Technology Item;Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 Detector type;VOx, 7.5 to 14μm Infrared resolution;1280×1024@12 μm Super resolution;Yes, Upgrade to 2560×2048 NETD;15 mK Frame rate;50Hz/9Hz Focal length;35 mm Field of view;25°×19° IFOV;0.34 mrad Min. object distance;0.3 m D:S;2916:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 50x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 800°C, Optional 400°C to 2500°C (High temperature lens is required) Measurement accuracy;±1°C or ±1%, whichever is greater Analyzed target;35 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, NFC connection, OTA update <strong>Image display</strong> Display screen;5.5’’ LCD, touch screen, 1920×1080 Eyepiece;OLED screen, 1920×1080 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;Dual visible light, up to 16MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 35m) Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (128 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) External interface;USB-C, DC (12V) , SD card slot, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;5G module (optional) Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;3.5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 <strong>Physical parameters</strong> Hardware;WIFI, Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen Weight;1.86 kg (with standard lens and battery) Size;191×171×118 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-A to USB-C cable, USB-C to Ethernet Adapter, Micro HDMI to HDMI cable, SD card (128 GB), Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame. Optional lenses: Wide-angle (45°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), High-temperature, Macro

PT850 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;1024×768@12 μm Super resolution;Yes, Upgrade to 2048×1536 NETD;25 mK Frame rate;50Hz/9Hz Focal length;27.7 mm Field of view;25°×19° IFOV;0.43 mrad Min. object distance;0.3 m D:S;2346:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 50x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 800°C, Optional 400°C to 2500°C (High temperature lens is required) Measurement accuracy;±1°C or ±1%, whichever is greater Analyzed target;35 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, NFC connection, OTA update <strong>Image display</strong> Display screen;5.5’’ LCD, touch screen, 1920×1080 Eyepiece;OLED screen, 1920×1080 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;Dual visible light, up to 16MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1 m to 35 m) Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (128 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) External interface;USB-C, DC (12V) , SD card slot, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;5G module (optional) Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 <strong>Physical parameters</strong> Hardware;Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen Weight;1.86 kg (with standard lens and battery) Size;191×128×170 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-A to USB-C cable, USB-C to Ethernet Adapter, Micro HDMI to HDMI cable, SD card (128 GB), Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame, Optional lenses: Wide-angle (45°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), High-temperature, Macro

PT650 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;640×512@12μm Super resolution;Yes, Upgrade to 1280×1024 NETD;30 mK Frame rate;50Hz/9Hz Focal length;17.6 mm Field of view;25°×19° IFOV;0.68 mrad Min. object distance;0.3 m D:S;1466:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 40x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, Optional 400°C to 2500°C (High temperature lens is required) Measurement accuracy;±1°C or ±1%, whichever is greater Analyzed target;30 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, NFC connection, OTA update <strong>Image display</strong> Display screen;5.5’’ LCD, touch screen, 1920×1080 Eyepiece;OLED screen, 1920×1080 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;Dual visible light, up to 13MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 35m) Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (128 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) External interface;USB-C, DC (12V) , SD card slot, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;5G module (optional) Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 <strong>Physical parameters</strong> Hardware;Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen Weight;1.86 kg (with standard lens and battery) Size;191×128×170 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-A to USB-C cable, USB-C to Ethernet Adapter, Micro HDMI to HDMI cable, SD card (128 GB), Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame, Optional lenses: Wide-angle (45°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), High-temperature, Macro

PT450 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;480×360@12 μm Super resolution;Yes, Upgrade to 960×720 NETD;30 mK Frame rate;50Hz/9Hz Focal length;12.94 mm Field of view;25°×19° IFOV;0.91 mrad Min. object distance;0.3 m D:S;1095:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 35x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, Optional 400°C to 2500°C (High temperature lens is required) Measurement accuracy;±1°C or ±1%, whichever is greater Analyzed target;25 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, NFC connection, OTA update <strong>Image display</strong> Display screen;5.5’’ LCD, touch screen, 1920×1080 Eyepiece;OLED screen, 1920×1080 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized Image adjustment,Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;Dual visible light, up to 13MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 35m) Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (128 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously, Irgd (with temp info) External interface;USB-C, DC (12V) , SD card slot, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Cellular network;5G module (optional) Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4.5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 <strong>Physical parameters</strong> Hardware;Illuminator, Microphone, Speaker, Electronic Compass, GPS, Status screen Weight;1.86 kg (with standard lens and battery) Size;191×128×170 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-A to USB-C cable, USB-C to Ethernet Adapter, Micro HDMI to HDMI cable, SD card (128 GB), Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame. Optional lenses: Wide-angle (45°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), High-temperature, Macro

PR610S specifications

<strong>Imaging and optics</strong> Core Technology Item;Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 Detector type;VOx, 7.5 to 14 μm Infrared resolution;640×480@12 μm NETD;15 mK Frame rate;60Hz/9Hz Focal length;9 mm Field of view;50°×37° IFOV;1.25 mrad Min. object distance;0.5 m D:S;800:1 Focusing mode;Focus-free Digital zoom;2x/4x/8x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, Optional 500°C to 2000°C (Aperture is required) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Three spots: Center, Maximum temperature, Minimum temperature. Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (Vibration, Screen flicker, Buzzer) Others;OTA update <strong>Image display</strong> Display screen;4.3" LCD, 800×480 Image mode;6 Modes: Basic fire fighting, Black and white, Fire scene, Search and rescue, Thermal detection, Standard Color palettes;8: Black Hot, White Hot, Iron Red, Arctic, Hot Iron, Rainbow 1, Fulgurite, Tint (Alternative palettes are supported only in Standard mode) Image adjustment;Level span mode: Automatic Digital camera;5MP (requires optional digital camera module) <strong>Functions</strong> Laser;Laser (requires optional digital camera module) Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in storage (128 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info). Irgd (with temp info), up to 50 Hz (optional) for temperature analysis External interface;USB-C, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours <strong>Environmental parameters</strong> Working temperature;General Working temperature range: -10°C to +50°C. Specific Working temperature ranges: 80°C: 30 minutes, 120°C: 10 minutes, 260°C: 5 minutes IP rating;IP67 Drop;2m drop test <strong>Physical parameters</strong> Hardware;WIFI, Speaker Weight;1.3 kg (with battery) Size;296×122×153 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens cover, Aperture, Lithium-ion battery (3 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C Cable, USB-A to USB-C Cable, Micro HDMI to HDMI Cable, Hand strap, Neck strap, Telescopic buckle, Lanyard, Carrying bag, Safety box, Quick Start Guide, Warranty card, Inspection report, Calibration certificate Options;Digital camera module, Battery, Tripod

PR410 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;384×288@12 μm NETD;45 mK Frame rate;60Hz/9Hz Focal length;9 mm Field of view;50°×37° IFOV;2.3 mrad Min. object distance;0.5 m D:S;435:1 Focusing mode;Focus-free Digital zoom;2x/4x/8x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, Optional 500°C to 2000°C (Aperture is required) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Three spots: Center, Maximum temperature, Minimum temperature. Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (Vibration, Screen flicker, Buzzer) Others;OTA update <strong>Image display</strong> Display screen;4.3" LCD, 800×480 Image mode;6 Modes: Basic fire fighting, Black and white, Fire scene, Search and rescue, Thermal detection, Standard Color palettes;8: Black Hot, White Hot, Iron Red, Arctic, Hot Iron, Rainbow 1, Fulgurite, Tint (Alternative palettes are supported only in Standard mode) Image adjustment;Level span mode: Automatic <strong>Functions</strong> Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in storage (128 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info), Irgd (with temp info), up to 30 Hz (optional) for temperature analysis External interface;USB-C, Micro HDMI, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours <strong>Environmental parameters</strong> Working temperature;General Working temperature range: -10°C to +50°C. Specific Working temperature ranges: 80°C: 30 minutes, 120°C: 10 minutes, 260°C: 5 minutes IP rating;IP67 Drop;2m drop test <strong>Physical parameters</strong> Hardware;WIFI, Speaker Weight;1.3 kg (with battery) Size;296×122×153 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device (with lens), Lens cover, Aperture, Lithium-ion battery (3 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C Cable, USB-A to USB-C Cable, Micro HDMI to HDMI Cable, Hand strap, Neck strap, Telescopic buckle, Lanyard, Carrying bag, Safety box, Quick Start Guide, Warranty card, Inspection report, Calibration certificate Options;Digital camera module, Battery, Tripod

FA611S specifications

<strong>Acoustic Sensor</strong> Microphone array;128 low-noise MEMS microphones Bandwidth;0 kHz to 65 kHz, Adjustable range SPL range;0~120 dB Frame rate;50 Hz/9 Hz Detection mode;Partial Discharge / Gas Leak <strong>Thermal Sensor (Thermal module required)</strong> Core Technology Item;Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 Detector type;VOx, 7.5 to 14 μm Infrared resolution;640×512@12 μm Super resolution;Yes, Upgrade to 1280×1024 NETD;15 mK Focal length;13 mm/17.7 mm Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C Measurement accuracy;±2°C or ±2%, whichever is greater <strong>Image display</strong> Display screen;10.1’’ LCD, touch screen, 1920×1200 Digital camera;13 MP Digital zoom;1.1x~20x Image mode;AU, IR, MIF, PIP <strong>Functions</strong> Laser;Support laser indication, laser ranging range of 0.1 m to 35 m Recording function;Photo and Video Cloud Services;Available OTA;Available <strong>Storage and transmission</strong> Storage media;External SD card (128 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously. Irgd (with temp info), up to 30 Hz (optional) for temperature analysis External interface;USB-C, SD card slot, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;Built-in battery + External battery: 4 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 <strong>Physical parameters</strong> Hardware;Illuminator, Microphone, Speaker, Electronic Compass, GPS Weight;1.7 kg to 2 kg (with built-in battery) Size;309×243.5×74 mm/309×243.5×100 mm Software kit;PC: ThermoTools, Mobile:FocusIR (iOS/Android) Package Content;Device (acoustic, module optional), Customized Batteries ×2, Desktop Charger,Power Adapter with Plugs, USB-A to USB-C Cable, USB-C to USB-C Cable, Micro HDMI to HDMI Cable, RJ45 Ethernet Patch Cable, Docking Station, SD Card (128GB), Shoulder Strap, Hand Strap, Carrying Case, Safety Box, Quick Start Guide, Inspection Report, Calibration Certificate, Warranty Card Optional Items;Tripod, Bluetooth Earphones, Optional module (Laser Rangefinder, Focus-free Thermal, Autofocus Thermal)

H6S specifications

<strong>Imaging and optics</strong> Core Technology Item;Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 Detector type;VOx, 7.5 to 14 μm Infrared resolution;640×480@12 μm Super resolution;Yes, Upgrade to 1280×960 NETD;15 mK Frame rate;50Hz/9Hz Focal length;17.7 mm Field of view;25°×19° IFOV;0.68 mrad Min. object distance;0.15 m D:S;1471:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 20x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, 500°C to 2000°C (RangeMax Ultra-wide measurement range lens kit is required) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;16 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (Image, Voice, Color and Flash) Others;Customized physical button, OTA update <strong>Image display</strong> Display screen;4.3" LCD, touch screen, 800×480 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;13 MP <strong>Functions</strong> Laser;Laser indication, Laser ranging 0.1 m to 40 m Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (64 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously. Irgd (with temp info), up to 50 Hz (optional) for temperature analysis External interface;USB-C, SD card slot, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Wi-Fi, Illuminator×2, Microphone, Speaker, Electronic Compass, GPS Weight;1.24 kg (with standard lens and battery) Size;292×125×125 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C cable, USB-A to USB-C cable, USB-C to Ethernet Adapter, SD card (64 GB) , Wrist strap, Shoulder strap, Carrying bag, Safety box, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Optional lenses: Wide-angle (44°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), RangeMax Ultra-wide Kit (25° / 15° / 7°), 3X Macro, Tripod, Docking station, Ethernet cable

H6+ specifications

<strong>Imaging and optics</strong> Detector resolution;Focal Plane Array, Uncooled Microbolometer, 640x480 pixels, non-interpolate Minimum Spectral Range Coverage;7.5 to 14 μm Image frame rate (on display);30 Hz, non-interlaced Thermal Sensitivity at 30°C (NETD);≤0.03 °C (30 mK) at 30 Hz image frame rate Field of view (FOV);24°×18° Instantaneous Field of View (IFOV);0.66 mrad Minimum Focus Distance;0.15 m Focus;Three focus systems: One shot contrast/passive auto focus, laser distance auto focus, manual focus Laser Pointer;Laser pointer including laser distance meter value Visual;Visual image shall be linked with corresponding thermal image Digital Zoom;1.0 - 20x Continuous Image Enhancement Mode;MIF (MSX Equivalent) <strong>Measurement and analysis</strong> Emissivity correction;Variable from 0.01 to 1.0 (at 0.01 step) or selected from listings in pre-defined material list Temperature Range;-40°C to 2,000 °C Accuracy;±2°C or ±2% of reading ,whichever is greater at 25°C ambient Measurement mode;16 movable spots, 16 areas (auto maximum and minimum temperature) Atmospheric transmission correction;Input correction for humidity, temperature, and measuring distance Reflected ambient temperature;Automatic, base on input of reflected temperature <strong>Image display</strong> Display screen;4.3” Colour Display, Touch Screen LCD (Resolution 800x480 pixels) <strong>Connection and Interfaces</strong> Interfaces;USB for connection between the camera and notebook computer Wireless Connection;Bluetooth Video Output;Display port to HDMI Programmable buttons;3 Buttons <strong>Environmental parameters</strong> Operating temperature;-20 °C to 50 °C Protection;IP54 Shock;25 G Vibration;2 G Drop Test;2 m Weight;1.2 kg (including battery) Warranty;1 Year <strong>Image Storage</strong> Storage media;Local storage (64 GB) and external SD card (64 GB and up to 256 GB) <strong>File Format</strong> Thermal;24 bit radiometric IR digital image <strong>Power System</strong> Battery;Rechargeable battery, at least 4 hours operation for each battery <strong>Accessories</strong> Accessories;60 seconds voice annotation with each image file, Video output port, Communication cable, Standard lens (IFOV not more than 0.66 mrad), One (1) set battery charger and three (3) sets battery, AC power adapter, single phase 230 VAC, 50 Hz, Data analysis software, Instruction manual in English and Thai, Other accessories according to manufacturer's design and auxiliary equipment necessary to complete <strong>Data Analysis and Reporting Software</strong> Software;Data analysis and reporting software comprising useful function for Windows operating system with: thumbnail image viewer, support drag and drop transfer of selected images from memory card to computer, independent emissivities correction variable from 0.01 to 1.0 select from listings in pre-defined material list (at 0.01 step), spot tools, area tools, line tools, with maximum, minimum and average temperature, Delta T calculation function, voice note replay, wizard driven report generation, the report can be modified by user

H4 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;480×360@12 μm Super resolution;Yes, Upgrade to 960×720 NETD;20 mK Frame rate;50Hz/9Hz Focal length;13.0 mm Field of view;25°×19° IFOV;0.91 mrad Min. object distance;0.15 m D:S;1099:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 16x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, 500°C to 2000°C (RangeMax Ultra-wide measurement range lens kit) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;12 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, OTA update <strong>Image display</strong> Display screen;4.3" LCD, touch screen, 800×480 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber, Customized Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;8 MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 40m) Recording function;Photo (image stitching) and Video (infrared & visible light) Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (64 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously. Irgd (with temp info), up to 50 Hz (optional) for temperature analysis External interface;USB-C, SD card slot, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;4 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP 54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Illuminator×2, Microphone, Speaker, Electronic Compass, GPS Weight;1.24 kg (with standard lens and battery) Size;292×125×125 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C cable, USB-A to USB-C cable, USB-C to Ethernet Adapter, SD card (64 GB) , Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame. Optional lenses: Wide-angle (44°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), RangeMax Ultra-wide Kit (25° / 15° / 7°), 3X Macro

H3+ specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;384×288@12 μm Super resolution;Yes, Upgrade to 768×576 NETD;30 mK Frame rate;50Hz/9Hz Focal length;10.5mm Field of view;25°×19° IFOV;1.14 mrad Min. object distance;0.15 m D:S;877:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 10x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, 500°C to 2000°C (RangeMax Ultra-wide measurement range lens kit) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;10 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, OTA update <strong>Image display</strong> Display screen;4.3" LCD, touch screen, 800×480 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;8 MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 40m) Recording function;Photo (image stitching) and Video Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (64 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously. Irgd (with temp info), up to 50 Hz (optional) for temperature analysis External interface;USB-C, SD card slot, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Bluetooth Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Illuminator×2, Microphone, Speaker, Electronic Compass, GPS Weight;1.24 kg (with standard lens and battery) Size;292×125×125 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C cable, USB-A to USB-C cable, USB-C to Ethernet Adapter, SD card (64 GB) , Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame. Optional lenses: Wide-angle (44°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), RangeMax Ultra-wide Kit (25° / 15° / 7°), 3X Macro

H3 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;320×240@12 μm Super resolution;Yes, Upgrade to 640×480 NETD;30 mK Frame rate;50Hz/9Hz Focal length;8.5 mm Field of view;25°×19° IFOV;1.36 mrad Min. object distance;0.15 m D:S;735:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 8x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, 500°C to 2000°C (RangeMax Ultra-wide measurement range lens kit) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;8 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, OTA update <strong>Image display</strong> Display screen;4.3" LCD, touch screen, 800×480 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera; 5MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1m to 40m) Recording function;Photo and Video Cloud Services;Available <strong>Storage and transmission</strong> Storage media;Built-in (64 GB) and external SD card (64 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously. Irgd (with temp info), up to 50 Hz (optional) for temperature analysis External interface;USB-C, SD card slot, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Illuminator×2, Microphone, Speaker, Electronic Compass, GPS Weight;1.24 kg (with standard lens and battery) Size;292×125×125 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C cable, USB-A to USB-C cable, USB-C to Ethernet Adapter, SD card (64 GB) , Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame. Optional lenses: Wide-angle (44°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), RangeMax Ultra-wide Kit (25° / 15° / 7°)

H2 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;256×192@12μm Super resolution;Yes, Upgrade to 512×384 NETD;30 mK Frame rate;50Hz/9Hz Focal length;6.8 mm Field of view;25°×19° IFOV;1.70 mrad Min. object distance;0.15 m D:S;588:1 Focusing mode;Manual / Automatic / Touch autofocus / Continuous autofocus Digital zoom;1.1x to 8x <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -40°C to 150°C, 0°C to 650°C, 500°C to 2000°C (RangeMax Ultra-wide measurement range lens kit) Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;5 in total (Spot/Line/Area) Alarm;Full screen temperature threshold alarm (image, voice, color and flash) Others;Customized physical button, OTA update <strong>Image display</strong> Display screen;4.3" LCD, touch screen, 800×480 Image mode;IR, VIS, MIF, PIP Color palettes;15: White Hot, Iron Red, Arctic, Rainbow 2, Hot Iron, Rainbow 1, Fulgurite, Medical, Tint, Black Hot, Blue Hot, Sepia, Green Hot, Ice and Fire, Amber Image adjustment;Level span mode: Automatic, Semi-automatic, Manual, Local dimming Digital camera;5 MP <strong>Functions</strong> Laser;Laser (Indication, Ranging 0.1 m to 40 m) Recording function;Photo and Video Cloud Services;Available <strong>Storage and transmission</strong> Storage medi; Built-in (64 GB) and external SD card (64 GB and up to 256 GB) Image storage;JPG with temp info Video storage;MP4 format (without temp info) can be used to record audio synchronously. Irgd (with temp info), up to 50 Hz (optional) for temperature analysis External interface;USB-C, SD card slot, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission Bluetooth;Bluetooth 5.0, support image transmission (only for Android) <strong>Power system</strong> Battery type;Lithium-ion rechargeable battery Operating time;5 hours <strong>Environmental parameters</strong> Working temperature;-20°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Illuminator×2, Microphone, Speaker, Electronic Compass, GPS Weight;1.24 kg (with standard lens and battery) Size;292×125×125 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device (with lens), Lens front and back cover, Lithium-ion battery (2 pcs), Desktop charger, Power adapter, Adapter plug, USB-C to USB-C cable, USB-A to USB-C cable, USB-C to Ethernet Adapter, SD card (64 GB) , Wrist strap, Shoulder strap, Safety box, Carrying bag, Quick Start Guide, Warranty Card, Inspection Report, Calibration Certificate Options;Battery, Carrying bag, Tripod, Bluetooth earphone, Docking station, Laboratory support frame. Optional lenses: Wide-angle (44°), Medium Telephoto (15°), Telephoto (7°), TwinView DFOV (25°+15° / 25°+45°), RangeMax Ultra-wide Kit (25° / 15° / 7°)

E4 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;384×288@12 μm Super resolution;Yes, Upgrade to 768×576 NETD;25 mK Frame rate;30Hz/9Hz Focal length;7 mm Field of view;37°×28° IFOV;1.71 mrad Min. object distance;0.3 m D:S;588:1 Focusing mode;Focus-free <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 0°C to 650°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Center spot, Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (image and flash) <strong>Image display</strong> Display screen;3.5" LCD , 640×480 Image mode;IR, VIS, MIF, PIP Color palettes;6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1 Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;2 MP <strong>Functions</strong> Laser;Laser Indication Recording function;Photo and Video <strong>Storage and transmission</strong> Storage medi; Built-in (32 GB) Image storage;JPG with temp info Video storage;Supports real-time video streaming, video storage format in Irgd (with temp info) External interface;USB-C, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;10 hours <strong>Environmental parameters</strong> Working temperature;-15°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Illuminator Weight;460 g Size;228×81×77.5 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device, Wrist strap, Power adapter, Adapter plug, USB-A to USB-C cable, Quick Start Guide, Warranty card, Carrying bag Options;Macro lenses (10x/5x), Tripod

E3S specifications

<strong>Imaging and optics</strong> Core Technology Item;Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 Detector type;VOx, 7.5 to 14 μm Infrared resolution;256×192@12 μm Super resolution;Support real-time super-resolution reconstruction, Upgrade to 512×384 NETD;15mK Frame rate;30Hz/9Hz Focal length;3.2 mm Field of view;56°×42° IFOV;3.82 mrad Min. object distance;0.3 m D:S;262:1 Focusing mode;Focus-free <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 0°C to 550°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Center spot, Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (Image and Flash) Others;OTA update <strong>Image display</strong> Display screen;3.5" LCD , 640×480 Image mode;IR, VIS, MIF, PIP Color palettes;6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1 Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;2 MP <strong>Functions</strong> Laser;Laser Indication Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in (32 GB) Image storage;JPG with temp info Video storage;Supports real-time video streaming, video storage format in Irgd (with temp info) External interface;USB-C, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;12 hours <strong>Environmental parameters</strong> Working temperature;-15°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Wi-Fi, Illuminator Weight;440 g Size;227×81×77.5 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device, Wrist strap, Carrying bag, Power adapter, Adapter plug, USB-A to USB-C cable, Quick Start Guide, Warranty card Options;Macro lenses (10x/5x), Tripod

E2S specifications

<strong>Imaging and optics</strong> Core Technology Item;Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm SharpIR 2.0 Detector type;VOx, 7.5 to 14 μm Infrared resolution;256×192@12 μm Super resolution;Support real-time super-resolution reconstruction, Upgrade to 512×384 NETD;15 mK Frame rate;25Hz/9Hz Focal length;3.2 mm Field of view;56°×42° IFOV;3.82 mrad Min. object distance;0.1 m D:S;262:1 Focusing mode;Focus-free <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 0°C to 550°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Center spot, Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (Image and Flash) <strong>Image display</strong> Display screen;2.4" LCD,240×320 Image mode;IR, VIS, MIF, PIP Color palettes;6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1 Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;2 MP <strong>Functions</strong> Laser;Laser Indication Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in (16 GB) Image storage;JPG with temp info Video storage;Supports real-time video streaming, video storage format in Irgd (with temp info) External interface;USB-C, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;11 hours <strong>Environmental parameters</strong> Working temperature;-15°C to 50°C IP rating;IP54 Drop;2 m drop test <strong>Physical parameters</strong> Hardware;Wi-Fi, Illuminator Weight;375 g Size 194×61.5×76 mm Software kit;PC: ThermoTools, Mobile: FocusIR (iOS/Android) Standard;A device, Wrist strap, Power adapter, Adapter plug, USB-A to USB-C cable, Quick Start Guide, Warranty card Options;Tripod

E2+ specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;256×192@12 μm Super resolution;Support real-time super-resolution reconstruction, Upgrade to 512×384 NETD;45 mK Frame rate;25Hz/9Hz Focal length;7 mm Field of view;25°×19° IFOV;1.71 mrad Min. object distance;0.1 m D:S;585:1 Focusing mode;Automatic <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 0°C to 550°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Center spot, Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (image and flash) Parameter settings;Emissivity, reflected temperature, target distance <strong>Image display</strong> Display screen;2.4" LCD Image mode;IR, VIS, MIF and PIP Color palettes;6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1 Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;2 MP <strong>Functions</strong> Laser;Laser Indication Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in (16 GB) Image storage;JPG with temp info Video storage;Supports real-time video streaming, video storage format in Irgd (with temp info) External interface;USB-C, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;11 hours Charging mode;USB-C charging, PC/portable charger, Capable of charging while using Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-15°C to 50°C IP rating;IP54 Drop;2 m drop test Certification;CE, FCC, RoHS, KC, EAC, FDA, Anatel, IP54, 2 m drop test, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator Weight;375 g Size;194×61.5×76 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device, Wrist strap, Power adapter, Adapter plug, USB-A to USB-C Cable, Data download card, Quick Start Guide, Warranty card, Inspection report Options;Tripod

E1+ specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;120×90@17 μm Super resolution;Support real-time super-resolution reconstruction, Upgrade to 240×180 NETD;60 mK Frame rate;25Hz/9Hz Focal length;2.28 mm Field of view;50°×38° IFOV;7.46 mrad Min. object distance;0.1 m D:S;130:1 Focusing mode;Focus-free <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 0°C to 550°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Center spot, Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (image and flash) Parameter settings;Emissivity, reflected temperature, target distance <strong>Image display</strong> Display screen;2.4" LCD Image mode;IR, VIS, MIF and PIP Color palettes;6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1 Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;2 MP <strong>Functions</strong> Laser;Laser Indication Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in (16 GB) Image storage;JPG with temp info Video storage;Supports real-time video streaming, video storage format in Irgd (with temp info) External interface;USB-C, Tripod socket WIFI;Yes, it can be connected to the mobile terminal for image and real-time video transmission <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;8 hours Charging mode;USB-C charging, PC/portable charger, Capable of charging while using Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-15°C to 50°C IP rating;IP54 Drop;2 m drop test Certification;CE, FCC, RoHS, KC, EAC, FDA, Anatel, IP54, 2 m drop test, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator Weight;355 g Size;194×61.5×76 mm Software kit;PC: ThermoTools, Mobile: Thermography (iOS/Android) Standard;A device, Wrist strap, Power adapter, Adapter plug, USB-A to USB-C Cable, Data download card, Quick Start Guide, Warranty card, Inspection report Options;Tripod

E1 specifications

<strong>Imaging and optics</strong> Detector type;VOx, 7.5 to 14 μm Infrared resolution;120×90@17 μm Super resolution;Support real-time super-resolution reconstruction, Upgrade to 240×180 NETD;60 mK Frame rate;25Hz/9Hz Focal length;2.28 mm Field of view;50°×38° IFOV;7.46 mrad Min. object distance;0.1 m D:S;130:1 Focusing mode;Focus-free <strong>Measurement and analysis</strong> Measurement range;Support auto-switching: -20°C to 150°C, 0°C to 550°C Measurement accuracy;±2°C or ±2%, whichever is greater Analyzed target;Center spot, Three Fixed Areas: Small, Medium, Large (Alternative) Alarm;Full screen temperature threshold alarm (image and flash) Parameter settings;Emissivity, reflected temperature, target distance <strong>Image display</strong> Display screen;2.4" LCD Image mode;IR, VIS, MIF and PIP Color palettes;6: Iron Red, White Hot, Arctic, Rainbow 2, Hot Iron, Rainbow 1 Image adjustment;Level span mode: Automatic, Semi-automatic, Manual Digital camera;2 MP <strong>Functions</strong> Laser;Laser Indication Recording function;Photo and Video <strong>Storage and transmission</strong> Storage media;Built-in (16 GB) Image storage;JPG with temp info Video storage;Video storage format in Irgd (with temp info) External interface;USB-C, Tripod socket <strong>Power system</strong> Battery type;Rechargeable lithium-ion battery, non-removable Operating time;8 hours Charging mode;USB-C charging, PC/portable charger, Capable of charging while using Charging time;90% of full charge in 2.5 hours <strong>Environmental parameters</strong> Working temperature;-15°C to 50°C IP rating;IP54 Drop;2 m drop test Certification;CE, FCC, RoHS, KC, EAC, FDA, Anatel, IP54, 2 m drop test, Damp heat test, Vibration test, Shock test, Impact test, UN38.3, MSDS <strong>Physical parameters</strong> Hardware;Illuminator Weight;355 g Size;194×61.5×76 mm Software kit;PC: ThermoTools Standard;A device, Wrist strap, Power adapter, Adapter plug, USB-A to USB-C Cable, Data download card, Quick Start Guide, Warranty card, Inspection report Options;Tripod
