Guide PS800
High-resolution handheld thermal imaging camera for advanced industrial diagnostics
Hurry up, only 3 kits left!
If you’re looking for a complete thermal imaging solution, this deal is for you.
Get the Guide Sensmart PS800 thermal camera kit with 3 additional lenses (Wide Angle, Telephoto, High Temperature).
The regular total value is EUR 40,000, now offered at a special promotional price of EUR 28,000, saving 30%. Act fast, only 3 kits are available, and the offer applies exclusively to the full kit purchase.
Delivery costs calculated individually. Customs duties paid by the customer.
What Is PS800 and Who It’s For
The Guide Sensmart PS800 puts professional thermal imaging in your hands, giving you clear and detailed thermal images in real working conditions. With a 1024×768 infrared sensor, high thermal sensitivity, and fast autofocus, you can quickly spot temperature differences and identify potential issues before they become problems. The PS800 is perfect for electricians, maintenance engineers, HVAC specialists, or industrial technicians who need accurate measurements, reliable image quality, and flexible optics. Use it for your routine inspections, fault detection, and preventive maintenance across industrial sites, commercial facilities, and outdoor environments.
Guide PS800 Key Features
-
Fast and Smart Autofocus
The PS800 features a new-generation focus motor and a professional laser rangefinder, achieving smart one-touch autofocus in just 0.4 seconds. -
AI Voice Recognition
PS800’s AI voice recognition helps you name and tag images using voice input and text recognition, streamlining file management and documentation. -
Calibration-Free Extended Lenses
The PS800 supports extended lenses (wide, telephoto, high-temp) that require no factory calibration, saving you time and cost while enabling more versatile application scenarios. -
Cloud Image Sharing
The PS800 allows you to share images to the cloud seamlessly, providing remote analysis and fast feedback. Wi-Fi connection options include a mobile hotspot and wireless router, with optional 4G mobile communication. -
MIF Patent Technology for Multi-Spectral Image Fusion
The PS800 provides four image modes: IR, visible light, PIP, and MIF. Its unique MIF mode fuses visible light details onto the thermal image, enhancing clarity, improving observation, and boosting work efficiency. -
Image Super-Resolution
The PS800 uses a special algorithm to enhance image details. Its super-resolution reconstruction increases infrared image resolution up to 4 times, delivering high-quality thermal images with improved clarity.
Guide PS800 Main Specifications
-
High-Resolution Infrared Sensor
The PS800 captures precise thermal images with a 1024×768 infrared sensor, delivering clear and detailed thermal visualization. -
High Thermal Sensitivity
The PS800 has a NETD ≤30 mK, which provides accurate readings in all working conditions. -
Wide Temperature Measurement Range
Measure temperatures from -40°C to 2000°C (with optional high-temperature lens) using the PS800 for industrial and outdoor applications. -
Large Color Touchscreen Display
The PS800 features a 5-inch high-contrast color LCD touchscreen, providing intuitive navigation and easy image viewing. -
Wireless Data Transfer and Storage
Store and export images with the PS800’s internal memory, SD card slot, and Wi-Fi/Bluetooth connectivity, streamlining reporting and documentation. -
Rugged Design for Industrial and Outdoor Use
The PS800 features IP54 protection, ensuring reliable performance in demanding industrial and outdoor environments.
How Guide PS800 works
The Guide Sensmart PS800 captures precise thermal data using a 1024 × 768 infrared detector with high thermal sensitivity, helping you detect even small temperature differences. It supports a wide temperature measurement range and rapid image acquisition with fast autofocus, so you can quickly lock onto targets. The built‑in high‑resolution visible camera enhances image clarity and alignment with thermal data. You control settings and view results on a large color display with intuitive interface. For flexible field use, the PS800 offers interchangeable lenses including wide angle, telephoto, and high‑temperature options, and stores data locally with options for wireless transfer.
Guide PS800 applications
The PS800 thermal imaging camera is used in many everyday professional tasks where temperature checks matter. It is commonly applied during electrical inspections to check switchboards, transformers, and power distribution systems. The camera is also helpful for mechanical maintenance, allowing technicians to spot overheating parts and friction issues early. In HVAC work, it helps identify heat loss, insulation problems, and airflow issues. The PS800 is also used for industrial inspections, building checks, and general field or research work.
-
Electrical inspections
-
Mechanical maintenance
-
HVAC
-
Industrial inspections
FAQ
Honest answers to important questions
A thermal camera detects infrared radiation emitted by objects and converts temperature differences into a visible thermal image, allowing you to see heat patterns invisible to the naked eye.
Thermal resolution refers to the number of pixels in the infrared sensor. Higher resolution provides more detailed thermal images and improves fault detection accuracy.
Thermal sensitivity, measured as NETD, indicates how well a camera can detect small temperature differences. Lower NETD values mean clearer images and more precise analysis.
Yes, thermal cameras measure surface temperatures and provide numerical readings, but accuracy depends on settings such as emissivity, distance, and environmental conditions.
Yes, many thermal cameras are designed for outdoor environments and can be used for inspections in varying weather and lighting conditions.
No, thermal cameras cannot see through solid walls, as these materials block infrared radiation. Instead, they detect surface temperature differences caused by heat conduction, such as those from pipes or leaks behind walls.
Contact us
You can order the equipment or ask questions here
